When it comes to construction projects, the space that you’re filling is equally as important as the structure that you’re building. That’s why site analysis is so important to a successful construction project; whatever you’re building must work in the space both aesthetically and structurally.
Since site analysis is so important, we’ll first define it and detail its purpose in construction project management. Then we’ll outline the steps involved in site analysis and share a site analysis checklist to ensure you do a thorough job.
What Is an Architecture Site Analysis?
Site analysis in architecture is a process that involves research and analysis of the social, historical, climatic, geographic, legal and infrastructure aspects of a location. This work is delivered visually, such as site analysis diagrams, which are then used when planning to build a structure or building.
Using the architecture site analysis with the other construction project data will allow architects to make more insightful decisions when designing their structure or building. They will be important documents during the design process and will influence the programmatic realities but also the structural and even aesthetic decisions. That is, the shape, form and materials used.
Architecture site analysis informs the design but it’s also helpful for the general contractor and various subcontractors that work under the general contractor. The owner of the construction project will want to know the results of a site analysis to help them make a decision about the viability of the project.
With all the various parties needed to share the architectural site analysis, designers, builders and owners need construction project management software that allows them to access these important diagrams in the office, in the field or while traveling. ProjectManager is construction project management software that delivers real-time communication anywhere and at any time. Unlimited file storage means the tool you use to manage and execute the project is also the central hub for site analysis and all project documentation. Get started with ProjectManager today for free.
What Is the Purpose of a Site Analysis?
You can look at site analysis diagrams as the graphic translation of key observations about the material conditions of the site. It’s clear why site analysis is so important; it provides an architect with data on sun and shade patterns, movement and circulation patterns and land use, as well as public space vs. private space.
But it’s not only the architect that benefits from site analysis. The client wants to know if the site chosen for the construction is viable and the site analysis allows the client to figure out if the property is financially feasible for development. It also establishes the parameter by which to create the best design for the physical and environmental features of the site.
Beyond serving the various parties involved in the construction project, a site analysis has the defined purpose of researching the existing conditions of the project site, including any imminent or potential future conditions, in order to inform the design process. Without a site analysis, the design is true without context. The site analysis allows the design team to understand the limitations and responses to their work as it applies to the external conditions of the site.
Some issues that’ll be examined over the course of the site analysis include its location, size, topography, zoning and traffic conditions as well as the climate of the area. Future developments must also be considered in addition to any changes that might occur on the site or surrounding area, such as road changes, cultural patterns and other significant buildings.
Site Analysis Steps
The more details you get, the better your site analysis will be. Designers need to understand the context of the building or structure they’re creating. How the construction will fit in the space and how that space impacts the construction are all key elements of the site analysis. Before construction can begin, you need to take these three steps to deliver a more informed architectural site analysis.
The first step is research. This isn’t isolated to the current physical condition and its surroundings, but also any relevant historical information about what the site looked like. You’ll want to see if there were any significant changes to the landscape and/or architecture of the site including what around the site is being analyzed.
Some useful tools are Google Street View but keep in mind that the tool only dates back to 2007. There are 3-D mapping tools that use volumetric references. The city or county in which the site is located will have property records that are often online including maps, zoning information, land ownership, school districts, transportation, utilities and more. Community centers, neighborhood associations, local historical societies and newspapers have archives and can be helpful in expanding the context of the site.
Of course, you’ll also want to physically visit the site to take pictures, notes and measurements. Capture the site’s dimensions, but also note its accessibility, whether there’s parking and any nearby transit. Gauge the level of noise, too. The more general impressions you make, the better for a full analysis.
Now that you’ve thoroughly researched the site, it’s time for the analysis phase as there should be a lot of information to sift through. See if you can find relationships between the disparate data. Some prefer a visual analysis while others use a more iterative diagramming of the site analysis. When analyzing the information, always remember the project goals and how the site might impact them.
Related: The Ultimate Guide to Construction Project Management
Synthesize the information you’ve collected and analyzed to inform the project within the context of every step and scale. The data you’ve gathered needs to be applicable to the project, relevant and easily digestible to serve a purpose. Otherwise, it’s just noise. You need to prioritize the information. Some site analysis is more important than other site analyses, especially through the lens of the design process. These data points inform the design parameter and decisions along that process and each of these steps is applied during the schematic design and programming phase.
Site Analysis Checklist: What to Look For
We’ve defined what an architectural site analysis is, the purpose for doing one and the steps to take in order to have a site analysis. Over the course of this blog, we’ve mentioned many things you’ll need to look out for when doing site analysis. To make it easier, we’ve compiled those and more in this site analysis checklist to ensure you don’t neglect key characteristics.
General data to collect includes the geographic location of the site, its boundaries and entrance locations and types. You’ll also want to note the site security, if any, and if there are any existing buildings on the site.
2. Context of the Neighborhood
Here’s where you look beyond the property and note the neighboring buildings. You’ll want to measure their distance from the site, their heights, if they are domestic or public buildings and what they’re being used for. Capture site lines, any legal restrictions and noise levels in the neighborhood.
3. Site and Zoning
Now what are the dimensions of the site and are there any easements, height restrictions and so forth. What is the site zoned for, commercial or residential?
4. Natural Features
Also important are the physical features of the site. For example, are there trees or other vegetation or rocks? You’ll want to map the topography. If there’s a river, pond or other body of water, that must be identified as well as the drainage patterns.
5. Man-Made Features
The other side of that coin is the man-made features. This can be an existing building or buildings, walls, surrounding vernacular, setbacks, materials, landscaping, etc., on the site.
6. Legal Restrictions
Don’t neglect the legal constraints on the site. These can range from who owns the property to any restrictions on the site including covenants and future urban development plans.
7. Access and Circulation
Note any public or private routes to the site. See if there is vehicle and/or pedestrian access. Figure out what, if any, are the existing circulation routes within the site.
Check to see if there are any electric, gas, water, sewer and telephone services attached to the property. If there are, note where they are located, distanced, depths and materials used.
9. Cultural and Human
More abstract but nonetheless important are the cultural, psychological, behavioral and sociological aspects of the neighborhood in which the site is located. Note activities that occur around the site, patterns, density of population and ethnic makeup, employment, income, values, etc.
Gather all of the climate data that you can. Note the average rainfall in the area, snowfall, wind directions, temperatures, and sun path and collect this information for every season in the year if it differs from time to time.
